Product Description

Selectable Languages Chinese, English, Japanese, French, German, Spanish, Portuguese and Russian;
Fonts Default font is Arial, allows users to load the fonts they need;
Barcodes UPCA, UPCE, EAN13, EAN8, INT25, CODE39, CODE128, ENA  128, PDF417, DATAMATRIX, QR;

(Allows user to add the barcode)

Date format Variety of date modes available (Production Date, Use by Date, Expiration Date, etc);
Device’s Database suport Provide standard port of  RS-232, Ethernet, easy to integrate for customers
PC Software’s Database MS Excel,  MS Access,  SQL2000,  SQL 2005,  SQL2008

Technical Parameters

Technology HP TIJ2.5;
Dimensions Controller(H*W*D): 210*135*37mm/8.3*5.3*1.46inch   One print head(H*W*D): 126*100*31mm/4.9*3.9*1.2inch   (Anti-shock cover is not included);
Power Supply AC 90V-240V/50-60HZ (Dedicated AC);
Printable Heights 1~76.2mm
Printing speed 0~60m/min(300DPI)


Resolution 50~600DPI
Port 1) Ethernet: 100Mb/s, Synchronized control of multiple devices via PC;   2) USB2.0: Support U-Disk;   3) DB15: For external devices like photocell, synchronizer or alarm kit connection;
Printing Objects Barcodes, Character, Numeric, Logos, Date/Time, Expiry Date, Shift Code, Counter, Lot-Box Code;
Interface 1) 7 inch 800 *480 color LCD touch screen; 2) With touch screen interface operation, easy to use; 3) Printer can work separately without PC software;
Ink management 1) Automatically recognize the ink types, and identify the optimum printing parameters;   2) Guarantee of using genuine original HP ink;   3) Automatic measuring system for the usage of the ink;


Mounting Standard side and downside printing assembly, customers can fix it flexibly;
Product Certification CE、FCC
Environment 1) Working Environment: -10°– +45°C;  10%-85%RH; 2) Storage Environment:  -25°– +55°C;  10%-90%RH;


Ink Solutions

Support porous, semi-porous and non-porous materials.
