Techik IMD-I-P Gravity Fall Metal Detector
Product Description
Metal Detector IMD-I-P Series
- Compact design, small machine foot print
- Rapid rejecting mechanism, to reduce the waste of the materials
- In line with the GMP requirements, easy to install and to clean
- Circuit design is more stable with a higher sensitivity than traditional analog detectors
- Specially designed mechanical structure, to minimize external interference like vibration, noise, product effect, etc
Specifications
| Model | IMD-I-P | ||||||
| Detection Diameter (mm) | Detection Capacity t/h2 | Alarm Mode | Pressure Requirements | Power Supply | Main Material | Sensitivity1 Φd (mm) | |
| Fe | SUS | ||||||
| 75 | 3 | Automatic Flap Rejecter |
0.5Mpa≥ |
AC220V (Optional) | Stainless Steel (SUS304) | 0.5 | 1.2 |
| 100 | 5 | 0.7 | 1.5 | ||||
| 150 | 10 | 0.8 | 1.5 | ||||
Note: The technical specifications above are the result of sensitivity testing with a known test sample. The sensitivity would be affected by the type of products being detected and working conditions.
